Networking

Every VM in your organization shares a private network. Services talk to each other over internal IPs with no extra configuration. When you need finer control, firewall rules, exposed ports, and deployment references give you precise networking between deployments.

Private network¶

When you provision your first VM, JuhJuh automatically creates a private network for your organization. Every subsequent VM joins this network. Services running on different VMs can connect to each other using internal IP addresses, the same way services on a local network would.

Each region where you run VMs gets its own subnet. Subnets are allocated automatically. You do not need to plan CIDR blocks or configure routing between regions.

graph LR
    subgraph Organization VPC
        subgraph Region A
            VM1[VM: app-server]
            VM2[VM: worker-server]
        end
        subgraph Region B
            VM3[VM: db-server]
        end
    end
    VM1 <-->|internal IP| VM2
    VM1 <-->|internal IP| VM3

Key points:

• One private network per organization, created automatically on first VM provision
• Each region gets its own subnet (auto-allocated)
• All VMs in the organization can reach each other over internal IPs
• No manual network setup, VPN configuration, or peering required

Firewall rules¶

Firewall rules control which ports on your VMs accept traffic and from where. Every rule targets a single port and specifies whether the port is open to the public internet or restricted to your private network.

Access levels¶

Defining rules in the JuhJuh File¶

Firewall rules can be defined at the root level (applied to all VMs) or on individual resources and services.

Root-level rules apply to every VM in the deployment:

yaml firewall: - port: 80 label: HTTP description: Public web traffic - port: 443 label: HTTPS description: Public web traffic (TLS) - port: 5432 access: internal label: PostgreSQL description: Database, private network only

Resource-level rules attach to a specific managed resource:

yaml resources: postgres: type: postgres firewall: - port: 5432 access: internal label: PostgreSQL

Rule fields¶

Restricting source ranges¶

For public ports that should only accept traffic from specific IPs (like a monitoring service or a partner API), set allowedSources:

yaml firewall: - port: 9090 label: Metrics allowedSources: - "203.0.113.0/24" - "198.51.100.5/32"

Infrastructure diagram¶

Public firewall rules appear in the infrastructure diagram on the PaaS dashboard. JuhJuh draws connection lines from the internet zone to the service or proxy that accepts the traffic. Internal rules stay within the private network zone. This gives your team a visual map of what is exposed and what is not.

Exposed ports¶

When a deployment runs a service that other deployments need to connect to, you expose specific ports on the organization network with a named alias. This is how one deployment discovers another.

yaml deployments: database: vm: db-server resources: [postgres] network: app-network expose: - port: 5432 alias: postgres protocol: tcp

Aliases must be unique within a deployment. You can expose multiple ports from the same deployment, each with a different alias.

Deployment references¶

Once a deployment exposes a port, other deployments can reference it using the ${deployment.<name>.<attribute>} syntax. JuhJuh resolves these references to actual IP addresses and port numbers at deploy time.

Available attributes¶

Wiring services together¶

A common pattern: one deployment runs your database, another runs the application. The application deployment references the database's exposed port:

```yaml deployments: database: vm: db-server network: app-network expose: - port: 5432 alias: postgres

app: vm: app-server network: app-network dependsOn: - deployment: database condition: healthy

envGroups: app-env: clear: DATABASE_HOST: "${deployment.database.host}" DATABASE_PORT: "${deployment.database.port.postgres}" DATABASE_URL: "postgres://user:pass@${deployment.database.endpoint.postgres}/mydb" ```

JuhJuh resolves ${deployment.database.endpoint.postgres} to something like 10.0.1.5:5432 when deploying the app. The dependsOn field ensures the database is healthy before the app starts.

Requirements for deployment references:

1. The target deployment must be listed in the referencing deployment's dependsOn field
2. Port and endpoint references require the target deployment to expose that alias
3. The target deployment must be provisioned and reporting a status before references resolve

Named networks¶

For deployments that need to communicate with each other, define a named network in the networks section of your JuhJuh File and assign it to each deployment.

```yaml networks: app-network: scope: organization driver: bridge subnet: auto

deployments: database: vm: db-server network: app-network expose: - port: 5432 alias: postgres

app: vm: app-server network: app-network ```

Network fields¶

Deployments on the same named network can communicate with each other. Use expose to make specific ports discoverable across the network.

Config-level network settings¶

You can also set network properties in the config section. This applies a default network to all services in the orchestration output:

yaml config: network: name: my-app-network driver: bridge

This is useful when all your services should share a single network without repeating the network name in every deployment.

Dashboard management¶

The PaaS dashboard shows your organization's network status:

• Infrastructure diagram. A visual map of your VMs, deployments, firewall rules, and network connections. Public ports show internet-facing connection lines. Internal ports stay within the private network zone.
• VM details. Each VM displays its static IP, internal IP, and the region subnet it belongs to.
• Deployment details. Each deployment shows its exposed ports, network attachment, and the resolved deployment references.

Firewall rules can be added during VM creation through the dashboard wizard or defined in the JuhJuh File. Both paths produce the same result.

Full example¶

A two-VM setup with a database and an application server, connected over a private network:

```yaml name: my-app

networks: internal: scope: organization driver: bridge subnet: auto

firewall: - port: 80 label: HTTP - port: 443 label: HTTPS - port: 5432 access: internal label: PostgreSQL

resources: postgres: type: postgres plan: standard config: max_connections: 200

vms: db-server: cpu: 2 memory_gb: 8 disk_gb: 100 app-server: cpu: 4 memory_gb: 16 disk_gb: 50

deployments: database: vm: db-server resources: [postgres] network: internal expose: - port: 5432 alias: postgres

app: vm: app-server image: registry.example.com/my-app tag: v1.0.0 network: internal services: [web, worker] dependsOn: - deployment: database condition: healthy

envGroups: app-env: clear: DATABASE_URL: "postgres://app:secret@${deployment.database.endpoint.postgres}/mydb"

services: web: type: web port: 8000 env_from: [app-env] worker: type: worker env_from: [app-env] ```

This configuration:

• Creates two VMs in your organization's private network
• Opens HTTP and HTTPS publicly, keeps the database port internal
• Exposes the database on the organization network with the alias postgres
• Wires the application to the database using deployment references
• Ensures the database is healthy before the application starts
